The USB console port +5VDC is input, and operates as an USB peripheral device.Note
USB Flash or MEM Port Pinouts
The table below summarizes the USB flash or MEM port pinouts.
Table 19: Single USB Flash or MEM Port Pinouts
DescriptionSignal NamePin
+5VDCVcc1
Data -D-2
Data +D+3
GroundGnd4
USB TYPE-A receptacle is used.Note
The USB flash or MEM port +5VDC is output. This router provides power for USB flash or MEM port.
This port operates as a USB host.
Note
Optical Fiber Specifications
The specification for optical fiber transmission defines two types of fiber: single mode and multimode. Within
the single-mode category, three transmission types are defined: short reach, intermediate reach, and long
reach. Within the multimode category, only short reach is available. For information about optical SFP modules,
see the documentation for the SFP module at: http://www.cisco.com/en/US/partner/products/hw/modules/
ps5455/prod_installation_guides_list.html .
Alarm Conditions
The table below summarizes the meaning of the alarm conditions on the Cisco ASR 920 Series Router.
