Step 2
Secure the cable guides with the four M6x12mm screws supplied with the cable kit. The recommended maximum torque
is 3N-m.
Figure 13: Installing the Cable Guides (As Per the Standard Kit)
Wall Mounting the Router
To install the router on a wall, follow the instructions in these procedures:
Attaching the Brackets to the Router for Wall-Mounting
While wall mounting the router, always ensure that the power supplies are at the top position.Note
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
49
Installing the Cisco ASR 920 Series Router
Wall Mounting the Router
