Cisco ASR-920-12SZ-IM Hardware Installation Guide

Power Supply ConditionFAIL LEDPower LED
PSU failure due to OCP, OTP, UV,
OV, OP, abnormal fan operation.
No valid output.
OnOff
Valid power present, shutdown by
system.
OffGreen 1Hz blinking
Input voltage lowOffYellow
No valid power input.OffOff
System–Interface LED Behavior
Table 9: 1G Copper and 1G SFP LED Indication
1G SFP Port LEDs1G Copper Port LEDs (Link)Event
OffOffROMMON
OffOffIOS Shut
AmberAmberIOS No shut (cable disconnect)
GreenGreenIOS No shut (Link Up)
Table 10: Dual Rate Port LED Indication
Dual Rate (1G/10G) Port LEDsEvent
OffROMMON
OffIOS Shut
AmberIOS No shut (cable disconnect)
GreenIOS No shut (Link Up)
Table 11: Management Port LED Indication
Management Port LEDs (Link/Duplex)Event
Green/OffROMMON
Off/OffIOS Shut
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
15
Cisco ASR 920 Series Aggregation Services Router Overview
LED Indicators

Cisco ASR-920-12SZ-IM Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
USB ports quantity	2
Ethernet LAN (RJ-45) ports	8
Product color	Gray
Rack capacity	1U
Antenna type	Not supported
AC input voltage	100 - 240 V
Power source type	AC, DC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	130 W
Non-operating altitude	0 - 4570 m
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, 2005, CAN/CSA C22.2 No. 60950-1: 2005, IEC 60950-1, 2005, EN 60950-1, 2005, AS/NZS 60950.1:2005
Electromagnetic compatibility	FCC CFR47 Part 15 Class A
Mean time between failures (MTBF)	407230 h
Firewall	-
Security algorithms	IPSec

Weight and Dimensions

Depth	286.54 mm
Width	444.5 mm
Height	44 mm
Weight	4830 g
