Cisco ASR-920-12SZ-IM Hardware Installation Guide

Powering On the Router
After the router is either rack mounted or mounted on the wall, perform these tasks to complete the installation:
•
Power on the router.
•
Connect the front-panel ports. See the Connecting to SFP Modules section to complete the installation.
Connecting the Router to the Network
The sections describe how to connect a router to the network:
Connect only SELV services to all the ports.Note
Connecting Console Cables
The sections describe how to connect to the router using console cables:
Connecting to the USB Serial Port Using Microsoft Windows
This procedure shows how to connect to the USB serial port using Microsoft Windows.
Install the USB device driver before establishing a physical connection between the router and the PC,
by using the USB console cable plugged into the USB serial port. Otherwise, the connection will fail. For
more information, see the Installing the Cisco USB Device Driver section.
Note
SUMMARY STEPS
1.
Connect a USB Type A-to-Type A cable to the USB console port. If you are using the USB serial port for
the first time on a Windows-based PC, install the USB driver now according to the instructions in the
following sections:
2.
Connect the USB Type A cable to the PC.
3.
To communicate with the router, start a terminal emulator application, such as Microsoft Windows
HyperTerminal. This software should be configured with the following parameters:
DETAILED STEPS
Step 1
Connect a USB Type A-to-Type A cable to the USB console port. If you are using the USB serial port for the first time
on a Windows-based PC, install the USB driver now according to the instructions in the following sections:
You cannot use the USB port and the EIA port concurrently. When the USB port is used, it takes priority over
the EIA port.
Note
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
80
Installing the Cisco ASR 920 Series Router
Powering On the Router

Cisco ASR-920-12SZ-IM Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
USB ports quantity	2
Ethernet LAN (RJ-45) ports	8
Product color	Gray
Rack capacity	1U
Antenna type	Not supported
AC input voltage	100 - 240 V
Power source type	AC, DC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	130 W
Non-operating altitude	0 - 4570 m
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, 2005, CAN/CSA C22.2 No. 60950-1: 2005, IEC 60950-1, 2005, EN 60950-1, 2005, AS/NZS 60950.1:2005
Electromagnetic compatibility	FCC CFR47 Part 15 Class A
Mean time between failures (MTBF)	407230 h
Firewall	-
Security algorithms	IPSec

Weight and Dimensions

Depth	286.54 mm
Width	444.5 mm
Height	44 mm
Weight	4830 g
