Cisco ASR-920-12SZ-IM Hardware Installation Guide

Table 6: SFP+ Port LED Indication
IndicationLED StateLED
Link up in 10G/1GGreenLabeled same as the SFP port
number
Activity in 10G/1GBlinking Green
Fault/Error/Link downAmber
Administratively downOff
RJ-45 LEDs
There is only one LED on each RJ45 port on the fixed slot (slot 0/0) and this indicates only the link or speed
status. There is no LED to show the Duplex state. However, there are two LEDs for IM RJ45 ports and they
indicate the Link and Duplex state.
Table 7: RJ-45 LED Indication
IndicationLED State
Link up in 10/100/1000Base-TGreen
Activity in 10/100/1000Base-TBlinking Green
Fault/Error/Link downAmber
Administratively downOff
Power Supply Unit LEDs
Each power supply unit has a corresponding LED on the front panel.
Table 8: PSU LED Indication
Power Supply ConditionFAIL LEDPower LED
Power Supply ON; valid
input/output
OffGreen
PSU Warning due to OCP, OTP,
UV, OV, OP, abnormal fan
operation
PSU continues to operate
Red 1Hz blinkingYellow 1Hz blinking
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
14
Cisco ASR 920 Series Aggregation Services Router Overview
LED Indicators

Cisco ASR-920-12SZ-IM Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
USB ports quantity	2
Ethernet LAN (RJ-45) ports	8
Product color	Gray
Rack capacity	1U
Antenna type	Not supported
AC input voltage	100 - 240 V
Power source type	AC, DC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	130 W
Non-operating altitude	0 - 4570 m
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, 2005, CAN/CSA C22.2 No. 60950-1: 2005, IEC 60950-1, 2005, EN 60950-1, 2005, AS/NZS 60950.1:2005
Electromagnetic compatibility	FCC CFR47 Part 15 Class A
Mean time between failures (MTBF)	407230 h
Firewall	-
Security algorithms	IPSec

Weight and Dimensions

Depth	286.54 mm
Width	444.5 mm
Height	44 mm
Weight	4830 g
