Cisco ASR-920-12SZ-IM Hardware Installation Guide

Activating an AC Power Supply Module
Perform the following procedure to activate an AC power supply:
SUMMARY STEPS
1.
Plug the power cord into the power supply.
2.
Connect the other end of the power cord to an AC-input power source.
3.
Verify power supply operation by checking if the respective power supply front panel LED (PS0 or PS1)
is green.
4.
If the LEDs indicate a power problem, see Troubleshooting for troubleshooting information.
5.
If you are connecting a redundant AC power supply, repeat these steps for the second power source.
DETAILED STEPS
Step 1
Plug the power cord into the power supply.
Step 2
Connect the other end of the power cord to an AC-input power source.
Step 3
Verify power supply operation by checking if the respective power supply front panel LED (PS0 or PS1) is green.
Step 4
If the LEDs indicate a power problem, see Troubleshooting for troubleshooting information.
Step 5
If you are connecting a redundant AC power supply, repeat these steps for the second power source.
If you are connecting a redundant AC power supply, ensure that each power supply is connected to a separate
power source in order to prevent power loss in the event of a power failure.
Note
Removing the AC Power Supply Module
This section describes how to remove and replace the AC power supply.
When you install the unit, the ground connection must always be made first and disconnected last. Statement
1046
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
Installation of the equipment must comply with local and national electrical codes. Statement 1074Warning
Follow these steps to remove and replace the AC power supply:
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
77
Installing the Cisco ASR 920 Series Router
Removing the AC Power Supply Module

Cisco ASR-920-12SZ-IM Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
USB ports quantity	2
Ethernet LAN (RJ-45) ports	8
Product color	Gray
Rack capacity	1U
Antenna type	Not supported
AC input voltage	100 - 240 V
Power source type	AC, DC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	130 W
Non-operating altitude	0 - 4570 m
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, 2005, CAN/CSA C22.2 No. 60950-1: 2005, IEC 60950-1, 2005, EN 60950-1, 2005, AS/NZS 60950.1:2005
Electromagnetic compatibility	FCC CFR47 Part 15 Class A
Mean time between failures (MTBF)	407230 h
Firewall	-
Security algorithms	IPSec

Weight and Dimensions

Depth	286.54 mm
Width	444.5 mm
Height	44 mm
Weight	4830 g
