Cisco ASR-920-12SZ-IM Hardware Installation Guide

DETAILED STEPS
Step 1
Choose Start > Control Panel > Add or Remove Programs .
Step 2
Scroll to Windows Driver Package - Exar corporation (xrusbser) Ports and click Remove. The Program Maintenance
window is displayed.
Step 3
Click Yes to uninstall the driver.
Connecting to the EIA Console Port
The US-to-RJ45 adapter cable and the DB9 console cable are not included with the router; they can be
ordered separately from Cisco.
Note
The serial console cable kit is not included with the router; it is ordered separately.Note
To connect a terminal to the EIA Console port on the router, follow these steps:
SUMMARY STEPS
1.
Connect the USB end of the USB-to RJ-45 cable to the EIA Console port.
2.
Connect the RJ-45 end of the DB-9 adapter cable to the USB-to RJ-45 cable, as shown in the following
figure.
3.
Connect the DB-9 end of the console cable to the DB-9 end of the terminal.
4.
To communicate with the router, start a terminal emulator application, such as Microsoft Windows
HyperTerminal. This software should be configured with the following parameters:
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
85
Installing the Cisco ASR 920 Series Router
Connecting to the EIA Console Port

Cisco ASR-920-12SZ-IM Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
USB ports quantity	2
Ethernet LAN (RJ-45) ports	8
Product color	Gray
Rack capacity	1U
Antenna type	Not supported
AC input voltage	100 - 240 V
Power source type	AC, DC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	130 W
Non-operating altitude	0 - 4570 m
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, 2005, CAN/CSA C22.2 No. 60950-1: 2005, IEC 60950-1, 2005, EN 60950-1, 2005, AS/NZS 60950.1:2005
Electromagnetic compatibility	FCC CFR47 Part 15 Class A
Mean time between failures (MTBF)	407230 h
Firewall	-
Security algorithms	IPSec

Weight and Dimensions

Depth	286.54 mm
Width	444.5 mm
Height	44 mm
Weight	4830 g
