Cisco ASR-920-12SZ-IM Hardware Installation Guide

Installing an Interface Module
Before inserting an interface module, make sure that the chassis is grounded.Caution
SUMMARY STEPS
1.
To insert the interface module, carefully align the edges of the interface module between the upper and
lower edges of the router slot.
2.
Carefully slide the interface module into the router slot until the interface module makes contact with the
backplane.
3.
Tighten the locking thumbscrews on both sides of the interface module. The recommended maximum
torque is 5.5 in.-lb (.62 N-m).
4.
Connect all the cables to each interface module.
DETAILED STEPS
Step 1
To insert the interface module, carefully align the edges of the interface module between the upper and lower edges of
the router slot.
Step 2
Carefully slide the interface module into the router slot until the interface module makes contact with the backplane.
Step 3
Tighten the locking thumbscrews on both sides of the interface module. The recommended maximum torque is 5.5 in.-lb
(.62 N-m).
Step 4
Connect all the cables to each interface module.
Removing an Interface Module
SUMMARY STEPS
1.
To remove an interface module, disconnect all the cables from the interface module.
2.
Loosen the locking thumbscrews on both sides of the interface module.
3.
Slide the interface module out of the router slot by pulling on the handles. If you are removing a blank
filler plate, pull the blank filler plate completely out of the router slot using the captive screws.
DETAILED STEPS
Step 1
To remove an interface module, disconnect all the cables from the interface module.
Step 2
Loosen the locking thumbscrews on both sides of the interface module.
Step 3
Slide the interface module out of the router slot by pulling on the handles. If you are removing a blank filler plate, pull
the blank filler plate completely out of the router slot using the captive screws.
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
64
Installing the Cisco ASR 920 Series Router
Installing an Interface Module

Cisco ASR-920-12SZ-IM Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
USB ports quantity	2
Ethernet LAN (RJ-45) ports	8
Product color	Gray
Rack capacity	1U
Antenna type	Not supported
AC input voltage	100 - 240 V
Power source type	AC, DC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	130 W
Non-operating altitude	0 - 4570 m
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, 2005, CAN/CSA C22.2 No. 60950-1: 2005, IEC 60950-1, 2005, EN 60950-1, 2005, AS/NZS 60950.1:2005
Electromagnetic compatibility	FCC CFR47 Part 15 Class A
Mean time between failures (MTBF)	407230 h
Firewall	-
Security algorithms	IPSec

Weight and Dimensions

Depth	286.54 mm
Width	444.5 mm
Height	44 mm
Weight	4830 g
