Cisco ASR-920-12SZ-IM Hardware Installation Guide

Uninstalling the Cisco USB Driver
Figure 31: Connecting the USB Console Cable to the Cisco ASR 920 Series Router
USB Type-A to USB
Type-A console cable
2USB Type-A console port1
This procedure describes how to uninstall the Microsoft Windows USB device driver in Microsoft Windows
XP, Windows Vista, Windows 2000, Windows 7, and Windows 8.
Disconnect the router console terminal before uninstalling the driver.Note
SUMMARY STEPS
1.
Choose Start > Control Panel > Add or Remove Programs .
2.
Scroll to Windows Driver Package - Exar corporation (xrusbser) Ports and click Remove. The Program
Maintenance window is displayed.
3.
Click Yes to uninstall the driver.
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
84
Installing the Cisco ASR 920 Series Router
Connecting Console Cables

Cisco ASR-920-12SZ-IM Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
USB ports quantity	2
Ethernet LAN (RJ-45) ports	8
Product color	Gray
Rack capacity	1U
Antenna type	Not supported
AC input voltage	100 - 240 V
Power source type	AC, DC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	130 W
Non-operating altitude	0 - 4570 m
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, 2005, CAN/CSA C22.2 No. 60950-1: 2005, IEC 60950-1, 2005, EN 60950-1, 2005, AS/NZS 60950.1:2005
Electromagnetic compatibility	FCC CFR47 Part 15 Class A
Mean time between failures (MTBF)	407230 h
Firewall	-
Security algorithms	IPSec

Weight and Dimensions

Depth	286.54 mm
Width	444.5 mm
Height	44 mm
Weight	4830 g
