Cisco ASR-920-12SZ-IM Hardware Installation Guide

CONTENTS
Preface 9
Document Revision History 9
Document Audience 9
Document Organization 9
Document Conventions 10
Obtaining Documentation and Submitting a Service Request 12
CHAPTER 1 Cisco ASR 920 Series Aggregation Services Router Overview 1
Cisco ASR 920 Router Features 1
GigabitEthernet Copper Ports 2
GE SFP Ports 2
SFP+ Ports 3
External Interfaces 8
Network Interfaces 8
Network Timing Interfaces 9
External Alarm Inputs 9
Management Interfaces 9
Management ENET Port 9
RS232 Console Port 9
USB Console 10
USB Mass Storage 10
Zero Touch Provisioning Button 10
RS232 Auxiliary Console Port 10
Power Supply and Fans 10
LED Indicators 11
PWR and STAT LEDs 11
CPU Management Port LEDs 13
SFP LEDs 13
SFP+ LEDs 13
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
iii

Cisco ASR-920-12SZ-IM Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
USB ports quantity	2
Ethernet LAN (RJ-45) ports	8
Product color	Gray
Rack capacity	1U
Antenna type	Not supported
AC input voltage	100 - 240 V
Power source type	AC, DC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	130 W
Non-operating altitude	0 - 4570 m
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, 2005, CAN/CSA C22.2 No. 60950-1: 2005, IEC 60950-1, 2005, EN 60950-1, 2005, AS/NZS 60950.1:2005
Electromagnetic compatibility	FCC CFR47 Part 15 Class A
Mean time between failures (MTBF)	407230 h
Firewall	-
Security algorithms	IPSec

Weight and Dimensions

Depth	286.54 mm
Width	444.5 mm
Height	44 mm
Weight	4830 g
