CommentIndicationSTAT LED statePWR LED State
System is in unresponsive
state.
FPGA Image Validation
Error.
RedAmber
—
Upgrade FPGA image
error, continuing with
Golden FPGA image.
AmberFlashing Amber and
Green alternatively
—
FPGA configuration
successful and Digital
code signing successfully
validated FPGA image.
Digital code signing
passed the control to
Microloader to boot
ROMMON.
OffFlashing Amber and
Green alternatively
—
Digital code signing
reported failure in
ROMMON image
validation.
RedFlashing Amber and
Green alternatively
Both LEDs turn Green
once provisioning is
complete.
ZTP process has begun.
A short press of
the ZTP button
triggers the
provisioning. A
longer press of
more than eight
seconds, resets
the board.
Note
Flashing AmberFlashing Amber
IOS-XE image is booting.OffGreen
—
Successfully booted and
system is operating
normally.
GreenGreen
—
A minor alarm or
synchronization is in
Holdover or free-running
mode
AmberGreen
—
A major or critical alarm
(high temperature
reported for any sensor)
or multiple fan failure.
RedGreen
Cisco ASR-920-12SZ-IM Aggregation Services Router Hardware Installation Guide
12
Cisco ASR 920 Series Aggregation Services Router Overview
LED Indicators

Cisco ASR-920-12SZ-IM Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
USB ports quantity	2
Ethernet LAN (RJ-45) ports	8
Product color	Gray
Rack capacity	1U
Antenna type	Not supported
AC input voltage	100 - 240 V
Power source type	AC, DC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	130 W
Non-operating altitude	0 - 4570 m
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Safety	UL 60950-1, 2005, CAN/CSA C22.2 No. 60950-1: 2005, IEC 60950-1, 2005, EN 60950-1, 2005, AS/NZS 60950.1:2005
Electromagnetic compatibility	FCC CFR47 Part 15 Class A
Mean time between failures (MTBF)	407230 h
Firewall	-
Security algorithms	IPSec

Weight and Dimensions

Depth	286.54 mm
Width	444.5 mm
Height	44 mm
Weight	4830 g
