Cisco Catalyst 2960-X User Manual

SUMMARY STEPS
1.
show ip http server status
2.
configure terminal
3.
ip http secure-server
4.
ip http secure-port port-number
5.
ip http secure-ciphersuite {[3des-ede-cbc-sha] [rc4-128-md5] [rc4-128-sha] [des-cbc-sha]}
6.
ip http secure-client-auth
7.
ip http secure-trustpoint name
8.
ip http path path-name
9.
ip http access-class access-list-number
10.
ip http max-connections value
11.
ip http timeout-policy idle seconds life seconds requests value
12.
end
DETAILED STEPS
PurposeCommand or Action
(Optional) Displays the status of the HTTP server to determine if the
secure HTTP server feature is supported in the software. You should see
one of these lines in the output:
HTTP secure server capability: Present
show ip http server status
Example:
Switch# show ip http server status
Step 1
or
HTTP secure server capability: Not present
Enters global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 2
Enables the HTTPS server if it has been disabled. The HTTPS server is
enabled by default.
ip http secure-server
Example:
Switch(config)# ip http secure-server
Step 3
(Optional) Specifies the port number to be used for the HTTPS server.
The default port number is 443. Valid options are 443 or any number in
the range 1025 to 65535.
ip http secure-port port-number
Example:
Switch(config)# ip http secure-port 443
Step 4
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
132 OL-29048-01
Configuring Secure Socket Layer HTTP
Configuring the Secure HTTP Server

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
