PurposeCommand or Action
(Optional) Specifies the CipherSuites (encryption algorithms) to be used
for encryption over the HTTPS connection. If you do not have a reason
ip http secure-ciphersuite
{[3des-ede-cbc-sha] [rc4-128-md5]
[rc4-128-sha] [des-cbc-sha]}
Step 5
to specify a particularly CipherSuite, you should allow the server and
client to negotiate a CipherSuite that they both support. This is the default.
Example:
Switch(config)# ip http
secure-ciphersuite rc4-128-md5
(Optional) Configures the HTTP server to request an X.509v3 certificate
from the client for authentication during the connection process. The
ip http secure-client-auth
Example:
Switch(config)# ip http
Step 6
default is for the client to request a certificate from the server, but the
server does not attempt to authenticate the client.
secure-client-auth
Specifies the CA trustpoint to use to get an X.509v3 security certificate
and to authenticate the client certificate connection.
ip http secure-trustpoint name
Example:
Switch(config)# ip http
Step 7
Use of this command assumes you have already configured a
CA trustpoint according to the previous procedure.
Note
secure-trustpoint your_trustpoint
(Optional) Sets a base HTTP path for HTML files. The path specifies
the location of the HTTP server files on the local system (usually located
in system flash memory).
ip http path path-name
Example:
Switch(config)# ip http path
Step 8
/your_server:80
(Optional) Specifies an access list to use to allow access to the HTTP
server.
ip http access-class access-list-number
Example:
Switch(config)# ip http access-class 2
Step 9
(Optional) Sets the maximum number of concurrent connections that are
allowed to the HTTP server. We recommend that the value be at least
10 and not less. This is required for the UI to function as expected.
ip http max-connections value
Example:
Switch(config)# ip http max-connections
Step 10
4
(Optional) Specifies how long a connection to the HTTP server can
remain open under the defined circumstances:
ip http timeout-policy idle seconds life
seconds requests value
Step 11
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 133
Configuring Secure Socket Layer HTTP
Configuring the Secure HTTP Server

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
