SUMMARY STEPS
1.
configure terminal
2.
access-list access-list-number {deny | permit} protocol source source-wildcard destination
destination-wildcard [precedence precedence] [tos tos] [fragments] [log [log-input] [time-range
time-range-name] [dscp dscp]
3.
access-list access-list-number {deny | permit} tcp source source-wildcard [operator port] destination
destination-wildcard [operator port] [established] [precedence precedence] [tos tos] [fragments] [log
[log-input] [time-range time-range-name] [dscp dscp] [flag]
4.
access-list access-list-number {deny | permit} udp source source-wildcard [operator port] destination
destination-wildcard [operator port] [precedence precedence] [tos tos] [fragments] [log [log-input]
[time-range time-range-name] [dscp dscp]
5.
access-list access-list-number {deny | permit} icmp source source-wildcard destination
destination-wildcard [icmp-type | [[icmp-type icmp-code] | [icmp-message]] [precedence precedence]
[tos tos] [fragments] [time-range time-range-name] [dscp dscp]
6.
access-list access-list-number {deny | permit} igmp source source-wildcard destination
destination-wildcard [igmp-type] [precedence precedence] [tos tos] [fragments] [log [log-input]
[time-range time-range-name] [dscp dscp]
7.
end
DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Defines an extended IPv4 access list and the access conditions.
access-list access-list-number {deny |
permit} protocol source source-wildcard
Step 2
The access-list-number is a decimal number from 100 to 199 or 2000 to 2699.
destination destination-wildcard [precedence
Enter deny or permit to specify whether to deny or permit the packet if
conditions are matched.
precedence] [tos tos] [fragments] [log
[log-input] [time-range time-range-name]
[dscp dscp]
For protocol, enter the name or number of an P protocol: ahp, eigrp, esp, gre,
icmp, igmp, igrp, ip, ipinip, nos, ospf, pcp, pim, tcp, or udp, or an integer
Example:
Switch(config)# access-list 101 permit
in the range 0 to 255 representing an IP protocol number. To match any Internet
protocol (including ICMP, TCP, and UDP), use the keyword ip.
This step includes options for most IP protocols. For additional
specific parameters for TCP, UDP, ICMP, and IGMP, see the
following steps.
Note
The source is the number of the network or host from which the packet is sent.
ip host 10.1.1.2 any precedence 0 tos
0 log
The source-wildcard applies wildcard bits to the source.
The destination is the network or host number to which the packet is sent.
The destination-wildcard applies wildcard bits to the destination.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 157
Configuring IPv4 ACLs
Creating a Numbered Extended ACL

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
