PurposeCommand or Action
Source, source-wildcard, destination, and destination-wildcard can be specified
as:
•
The 32-bit quantity in dotted-decimal format.
•
The keyword any for 0.0.0.0 255.255.255.255 (any host).
•
The keyword host for a single host 0.0.0.0.
The other keywords are optional and have these meanings:
• precedence—Enter to match packets with a precedence level specified
as a number from 0 to 7 or by name: routine (0), priority (1), immediate
(2), flash (3), flash-override (4), critical (5), internet (6), network (7).
• fragments—Enter to check non-initial fragments.
• tos—Enter to match by type of service level, specified by a number from
0 to 15 or a name: normal (0), max-reliability (2), max-throughput
(4), min-delay (8).
• log—Enter to create an informational logging message to be sent to the
console about the packet that matches the entry or log-input to include
the input interface in the log entry.
• time-range—Specify the time-range name.
• dscp—Enter to match packets with the DSCP value specified by a
number from 0 to 63, or use the question mark (?) to see a list of available
values.
If you enter a dscp value, you cannot enter tos or precedence. You
can enter both a tos and a precedence value with no dscp.
Note
Defines an extended TCP access list and the access conditions.
access-list access-list-number {deny | permit}
tcp source source-wildcard [operator port]
Step 3
The parameters are the same as those described for an extended IPv4 ACL,
with these exceptions:
destination destination-wildcard [operator
port] [established] [precedence precedence]
(Optional) Enter an operator and port to compare source (if positioned after
source source-wildcard) or destination (if positioned after destination
[tos tos] [fragments] [log [log-input]
[time-range time-range-name] [dscp dscp]
[flag]
destination-wildcard) port. Possible operators include eq (equal), gt (greater
than), lt (less than), neq (not equal), and range (inclusive range). Operators
require a port number (range requires two port numbers separated by a space).
Example:
Switch(config)# access-list 101 permit
Enter the port number as a decimal number (from 0 to 65535) or the name of
a TCP port. Use only TCP port numbers or names when filtering TCP.
tcp any any eq 500
The other optional keywords have these meanings:
• established—Enter to match an established connection. This has the
same function as matching on the ack or rst flag.
• flag—Enter one of these flags to match by the specified TCP header
bits: ack (acknowledge), fin (finish), psh (push), rst (reset), syn
(synchronize), or urg (urgent).
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
158 OL-29048-01
Configuring IPv4 ACLs
Creating a Numbered Extended ACL

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
