Cisco Catalyst 2960-X User Manual

DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode. Enter your password if prompted.enable
Step 1
Example:
Switch> enable
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 2
Use one of the following:
Step 3
•
Defines a new password or changes an existing password for
access to privileged EXEC mode.
•
enable password [level level]
{password | encryption-type
encrypted-password}
•
Defines a secret password, which is saved using a nonreversible
encryption method.
◦
(Optional) For level, the range is from 0 to 15. Level 1 is
normal user EXEC mode privileges. The default level is 15
(privileged EXEC mode privileges).
•
enable secret [level level]
{password | encryption-type
encrypted-password}
◦
For password, specify a string from 1 to 25 alphanumeric
characters. The string cannot start with a number, is case
Example:
Switch(config)# enable password
example102
sensitive, and allows spaces but ignores leading spaces. By
default, no password is defined.
◦
(Optional) For encryption-type, only type 5, a Cisco
proprietary encryption algorithm, is available. If you specify
or
Switch(config)# enable secret level 1
password secret123sample
an encryption type, you must provide an encrypted
password—an encrypted password that you copy from
another switch configuration.
If you specify an encryption type and then enter a clear
text password, you can not re-enter privileged EXEC
mode. You cannot recover a lost encrypted password by
any method.
Note
(Optional) Encrypts the password when the password is defined or when
the configuration is written.
service password-encryption
Example:
Switch(config)# service
Step 4
Encryption prevents the password from being readable in the
configuration file.
password-encryption
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 25
Controlling Switch Access with Passwords and Privilege Levels
Protecting Enable and Enable Secret Passwords with Encryption

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
