7-4
Catalyst 6500 Series Switch SIP, SSC, and SPA Hardware Installation Guide
OL-9041-04
Chapter 7 Troubleshooting the Installation
Packing a SIP for Shipment
Caution Always handle the SPA by the carrier edges and handle; never touch the SPA components or connector
pins.
Step 2 Close the Thermoform container. Be sure to lock the snaps securely.
Step 3 Check that the Thermoform container is fully closed. Apply tape or a label closure over the opening to
ensure the container stays closed during shipping.
Step 4 Place the Thermoform container into the carton.
Step 5 Close the carton.
Step 6 Apply tape over the carton flap to ensure the carton stays closed during shipping.
Packing a SIP for Shipment
This section provides step-by-step instructions for packing a SIP for shipment. Before beginning this
procedure, you should have the following original Cisco Systems packaging materials:
• Static shielding bag
• Smaller inner carton
• Larger exterior carton
• Two foam packing cushions
Caution The Cisco Systems original packaging is to be used for the shipment of all SIPs. Failure to properly use
Cisco Systems packaging can result in damage or loss of product.
Warning
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself.
Note These instructions assume that the SIP has been removed from the router according to the recommended
procedures specified in this guide.
To pack a SIP for shipment, perform the following steps:
Step 1 Insert the SIP into the static shielding bag.
Step 2 Insert the bagged SIP into the smaller inner carton. Be careful to position the SIP so that the bottom
motherboard lip is held by the packaging cutout.
Step 3 Close the smaller inner carton and tape the sides closed.
Step 4 Place the sealed smaller inner carton containing the SIP into the two foam packing cushions (they only
fit one way).
