Chapter 1 SIP, SSC, and SPA Product Overview
Power Management
Power Management
SPAs and SIPs consume chassis power, and, you must make sure the chassis is within the power budget
on a Catalyst
6500 Series switch.
Ta b l e 1-8 SIP and SPA Power Consumption
SIP Power Consumption (Maximum in Watts)
Cisco 7600 SIP-200 240.0
1
Cisco 7600 SIP-400 265.0
1
1. Maximum with four SPAs installed
Cisco 7600 SIP-600 341.0
2
2. Maximum with one SPA installed
Cisco 7600 SSC-400 235.0
3
3. Maximum with two IPSec VPN SPAs installed
SPA
2-Port Channelized T3 SPA 11.24
4-Port Channelized T3 SPA 13.14
8-Port Channelized T1/E1 SPA 9.4
2-Port OC-3c/STM-1 ATM SPA 24.6
4-Port OC-3c/STM-1 ATM SPA 24.8
1-Port OC-12c/STM-4 ATM SPA 25.1
1-Port OC-48c/STM-16 ATM SPA 38.13
1-Port OC-192c/STM-64 POS/RPR SPA 23.8
4
4. Includes LR optics as they are fixed on the board
1-Port OC-192c/STM-64 POS/RPR XFP
SPA
11.0
5
5. In addition to SFP or XFP optics power
1-Port OC-192c/STM-64 POS/RPR VSR
Optics SPA
11.0
2-Port OC-3c/STM-1 POS SPA 13.07
4-Port OC-3c/STM-1 POS SPA 13.82
1-Port OC-12c/STM-4 POS SPA 12.75
1-port OC-48/STM-16 ATM SPA 38.0
2-Port Clear Channel T3/E3 SPA 7.8
4-Port Clear Channel T3/E3 SPA 8.5
IPSec VPN SPA 40.0
1-Port 10-Gigabit Ethernet SPA 17.4
5
2-Port Gigabit Ethernet SPA 12.9
5-Port Gigabit Ethernet SPA 13.1
5
10-Port Gigabit Ethernet SPA 15.0
5
