3-37
Catalyst 6500 Series Switch SIP, SSC, and SPA Hardware Installation Guide
OL-9041-04
Chapter 3 Catalyst 6500 Series Switch SPA Overview
1-Port OC-192c/STM-64 POS/RPR VSR Optics SPA Overview
Table 3-19 describes the 1-Port OC-192c/STM-64 POS/RPR VSR Optics SPA LEDs.
1-Port OC-192c/STM-64 POS/RPR VSR Optics SPA Interface Specifications
The 1-Port OC-192c/STM-64 POS/RPR VSR Optics SPA contains a SONET/SDH framer to process
incoming and outgoing SONET or SDH frames. The framer operates at OC-192/STM-64 line rates (9.95
Gbps).
Packet data is transported with a user-configured encapsulation (such as Point-to-Point Protocol [PPP])
and is mapped into the STS-192c/STM-64 frame.
The 1-Port OC-192c/STM-64 POS/RPR VSR Optics SPA interface is compliant with the following
RFCs:
• RFC 1662, PPP in HDLC-like Framing
• RFC 2615, PPP over SONET/SDH
Ta b l e 3-19 1-Port OC-192c/STM-64 POS/RPR VSR Optics SPA LEDs
LED Label Color State Meaning
WRAP Off Off Port is not in wrap mode.
Green On Port is in wrap mode somewhere on the ring.
Amber On Port is in wrap mode locally.
PASSTHRU Off Off Port is not in pass-through mode.
Amber On Port is in pass-through mode.
MATESYNC Off Off Mate port is not synchronized.
Green On Mate port is synchronized.
CARRIER Off Off Port is not enabled by software.
Green On Port is enabled by software, and there is a valid SONET signal
without alarms.
Amber On Port is enabled by software, and there is at least one alarm
(LOS, LOF, RDI, and so on).
Blinking SRP mode mismatch alarm is indicated.
ACTIVE Off Off Port is not enabled by software.
Green On Port is enabled by software, and loopback is off.
Amber On Port is enabled by software, and loopback is on.
STATUS Off Off SPA power off.
Green On SPA is ready and operational.
Amber On SPA power is on and good, and the SPA is being configured.
