3-39
Catalyst 6500 Series Switch SIP, SSC, and SPA Hardware Installation Guide
OL-9041-04
Chapter 3 Catalyst 6500 Series Switch SPA Overview
4-Port and 8-Port Fast Ethernet SPA Overview
Figure 3-30 SPA Mate Cables
4-Port and 8-Port Fast Ethernet SPA Overview
The following sections describe the 4-Port and 8-Port Fast Ethernet SPA:
4-Port and 8-Port Fast Ethernet SPA LEDs, page 3-39
Cables, Connectors, and Pinouts, page 3-40
4-Port and 8-Port Fast Ethernet SPA LEDs
The 4-Port and 8-Port Fast Ethernet SPA has two types of LEDs. There is a port number Active/Link
LED for each individual port and one STATUS LED.
Figure 3-31 shows the 8-Port FastEthernet SPA
ports and LEDs.
Figure 3-31 8-Port FastEthernet SPA Faceplate
1 Long length RPR mate cable for single port
RPR SPAs (CBL-RPR-OC192-L)
2 Short length RPR mate cable for single port
RPR SPAs (CAB-RPR-OC192-S)
129198
1
2
1 A/L (Active/Link) LED 2 STATUS LED
138712
STATUS
A/L
SPA-8X1FE-TX-V2
0
A/L
1
A/L
2
A/L
3
A/L
4
A/L
5
A/L
6
A/L
7
1 2
