Cisco Catalyst 6500 Series Configuration Note

3-4
Catalyst 6500 Series Content Switching Module Configuration Note
OL-4612-01
Chapter 3 Getting Started
Configuring SLB Modes
• Differences Between CSM and RP Modes, page 3-5
• Changing Modes, page 3-7
Mode Command Syntax
Before you can enter CSM configuration commands on the switch, you must specify the CSM that you
want to configure. To specify a CSM for configuration, use the module csm slot-number command. The
slot-number value is the chassis slot where the CSM being configured is located.
The module csm command places you in CSM configuration submode. All additional configuration
commands that you enter apply to the CSM installed in the slot you have specified.
Note Unless otherwise specified, all the examples in this publication assume that you have already entered
this command and entered the configuration submode for the CSM you are configuring.
The command syntax for CSM mode and RP mode configuration is identical with these exceptions:
• When configuring in CSM mode, you must prefix each top-level command with ip slb.
• Prompts are different for CSM mode and for RP mode configurations.
To configure a virtual server for a CSM in slot 5, perform this task:
This example shows the complete list of CSM commands in the config-module-csm mode.
Router# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)# module csm 5
Router(config-module-csm)# ?
SLB CSM module config
arp configure a static ARP entry
capp configure Content Application Peering Protocol
default Set a command to its defaults
dfp configure Dynamic Feedback Protocol manager
exit exit SLB CSM module submode
ft configure CSM fault tolerance (ft) feature
map configure an SLB map
natpool configure client nat pool
no Negate a command or set its defaults
owner configure server owner
policy configure an SLB policy
probe configure an SLB probe
real configure module real server
script configure script files and tasks
serverfarm configure a SLB server farm
static configure static NAT for server initiated connections
sticky configure a sticky group
variable configure an environment variable
vlan configure a vlan
vserver configure an SLB virtual server
xml-config settings for configuration via XML
Command Purpose
Step 1
Router(config)# module csm 5
Specifies the location of the CSM you are configuring.
Step 2
Router(config-module-csm)# vserver
VS1
Configures the virtual server.
