Step 2 Align the slots on the strap-down clip with the knurled screws installed on the chassis and push down until it snaps in
place.
Step 3 Repeat Step 2, on page 68 for the other strap-down clip.
Step 4 Attach the snap-on plastic guides on the strap-down clip, as necessary.
Ensure that the orientation of the fiber or cable routing guide is proper by placing the smaller slot used for fiber
on the top.
Note
Cisco Converged Broadband Routers Hardware Installation Guide
68
Installing the Cisco cBR Chassis
Attaching the Fiber or Cable Routing Guide on Chassis
