Cisco GS7000 - Tools and Test Equipment

Chapter 3 Setup and Operation
64 OL-29936-01
8 Wavelength System
An 8 wavelength system is designed to have a maximum capacity of 8 optical
channels. The actual number of optical channels at the deployment can be 8 or less.
Model
Set Gain (Gc)
Composite Input (P
IN/C
)
(1λ  8 λ)
Composite Output (P
OUT/C
)
(1λ  8 λ)
GS-EDFA-GF-
17L-SA
5 dB
6 dB
7 dB*
8 dB
9 dB
3 dBm  12 dBm
2 dBm  11 dBm
1 dBm  10 dBm
0 dBm  9 dBm
-1 dBm  8 dBm
8 dBm  17 dBm
8 dBm  17 dBm
8 dBm  17 dBm
8 dBm  17 dBm
8 dBm  17 dBm
GS-EDFA-GF-
17H-SA
10 dB
11 dB
12 dB*
13 dB
14 dB
-2 dBm  7 dBm
-3 dBm  6 dBm
-4 dBm  5 dBm
-5 dBm  4 dBm
-6 dBm  3 dBm
8 dBm  17 dBm
8 dBm  17 dBm
8 dBm  17 dBm
8 dBm  17 dBm
8 dBm  17 dBm
GS-EDFA-GF-
21L-SA
9 dB
10 dB
11 dB*
12 dB
13 dB
3 dBm  12 dBm
2 dBm  11 dBm
1 dBm  10 dBm
0 dBm  9 dBm
-1 dBm  8 dBm
12 dBm  21 dBm
12 dBm  21 dBm
12 dBm  21 dBm
12 dBm  21 dBm
12 dBm  21 dBm
GS-EDFA-GF-
21H-SA
14 dB
15 dB
16 dB*
17 dB
18 dB
-2 dBm  7 dBm
-3 dBm  6 dBm
-4 dBm  5 dBm
-5 dBm  4 dBm
-6 dBm  3 dBm
12 dBm  21 dBm
12 dBm  21 dBm
12 dBm  21 dBm
12 dBm  21 dBm
12 dBm  21 dBm
* Default gain setting
