Viewing the Cisco RV180/RV180W Status
Viewing the System Summary
Cisco RV180/RV180W Administration Guide 165
8
WAN (Internet) Information (IPv6)
Wireless Information (Cisco RV180W)
Connection Time The time duration for which the connection is up.
Connection Type Indicates if the WAN IPv6 address is obtained
dynamically through a DHCP server, assigned
statically by the user, or obtained through a PPPoE/
PPTP/L2TP ISP connection.
Connection State Indicates if the WAN port is connected to the ISP.
IP Address The IP address of the WAN port.
Gateway The gateway IP address of the WAN port.
DNS Server DNS server IP address of the WAN port.
Release/Renew Visible if automatic configuration - DHCP is
connected as the Internet connection type. Click
Release to release the current IP address that was
assigned to your WAN port. Click Renew to obtain
a new IP address for your WAN port.
Connect/Disconnect Visible if an Internet connection type other than
automatic (DHCP) has been chosen. Click Connect
to connect to the selected server. Click Disconnect
to disconnect from the server to which you are
connected.
Operating Frequency Displays the operational frequency band.
Wireless Network Mode Displays the Wi-Fi mode of the radio (for example,
N or N/G).
Channel Displays the current channel in use by the radio.
