Configuring Networking
Configuring the LAN (Local Network) Settings
Cisco RV180/RV180W Administration Guide 35
2
Enabling VLANs
STEP 1 Choose Networking > LAN (Local Network) > VLAN Membership.
STEP 2 Check the Enable box.
STEP 3 Click Save.
Under the Enable VLAN field, The VLAN Membership Table is shown. This shows
available VLANs, including the VLAN ID, description, ports, and whether inter-
VLAN routing is enabled or not for each configured VLAN.
Creating a VLAN
You can create up to four VLANs on the Cisco RV180/RV180W.
STEP 1 Choose Networking > LAN (Local Network) > VLAN Membership.
STEP 2 In the VLAN Membership Table, click Add Row.
STEP 3 Enter a numerical VLAN ID that will be assigned to endpoints in the VLAN
membership. The VLAN ID can range from 2 to 4093. VLAN ID 1 is reserved for the
default VLAN, which is used for untagged frames received on the interface, and
VLAN ID 4094 is reserved and cannot be used.
STEP 4 Enter a description for the VLAN.
STEP 5 To enable routing between this and other VLANS, under Inter VLAN Routing, check
the Enable box.
STEP 6 To enable device management, check the Device Management box. This allows
you to access the Device Manager from that VLAN. For example, if you created a
VLAN with the VLAN ID of 2 and enabled device management, you can access the
Device Manager by using the first IP address on the created VLAN (for example,
192.168.2.1).
STEP 7 Under each of the ports for the VLAN, choose one of the following:
• Ta g g e d —Used when connecting to switches carrying multiple VLANs.
• Untagged—Access ports connecting to end devices like printers and
workstations.
STEP 8 Click Save.
