191
Chapter 11: Configuring SNMP
Defining Trap Management
SGE2000/SGE2000P Gigabit Ethernet Switch Reference Guide
Chapter
11
– SNMP V2 — Indicates SNMP Version 2 traps are sent.
• UDP Port — Displays the UDP port used to send notifications. The default is 162.
• Filter Name — Indicates if the SNMP filter for which the SNMP Notification filter is defined.
• Timeout — Indicates the amount of time (seconds) the device waits before re-sending informs. The
default is 15 seconds.
• Retries — Indicates the amount of times the device re-sends an inform request. The default is 3
seconds.
TheSNMPv3 Notification Recipient table area contains the following fields:
• Recipients IP — Indicates the IP address to whom the traps are sent.
• Notification Type — Defines the notification sent. The possible field values are:
– Trap — Indicates traps are sent.
– Inform — Indicates informs are sent.
• User Name — Displays the SNMP Communities.
– Security Level — Defines the means by which the packet is authenticated. The possible
field values are:
– No Authentication — Indicates the packet is neither authenticated nor encrypted.
– Authentication — Indicates the packet is authenticated.
– Privacy — Indicates the packet is both authenticated and encrypted.
• UDP Port — Displays the UDP port used to send notifications. The default is 162.
• Filter Name — Indicates if the SNMP filter for which the SNMP Notification filter is defined.
• Timeout — Indicates the amount of time (seconds) the device waits before re-sending informs. The
default is 15 seconds.
• Retries — Indicates the amount of times the device re-sends an inform request. The default is 3
seconds.
2. Click the Add button. The Add SNMP Notification Recipient Page opens
