99
Chapter 5: Configuring Device Interfaces
Configuring LACP
SGE2000/SGE2000P Gigabit Ethernet Switch Reference Guide
Chapter
5
– 10 Full — Indicates that the LAG is advertising a 10 mbps speed and full Duplex mode
setting.
– 100 Half —Indicates that the LAG is advertising a 100 mbps speed and half Duplex mode
setting.
– 100 Full — Indicates that the LAG is advertising a 100 mbps speed and full Duplex mode
setting.
– 1000 — Indicates that the LAG is advertising a 1000 mbps speed and full Duplex mode
setting.
• Current Advertisement — The LAG advertises its capabilities to its neighbor LAG to start the
negotiation process. The possible field values are those specified in the Admin Advertisement field.
• Neighbor Advertisement — The neighbor LAG (the LAG to which the selected interface is
connected) advertises its capabilities to the LAG to start the negotiation process. The possible values
are those specified in the Admin Advertisement field.
• Admin Speed — The configured speed at which the LAG is operating.
• Current LAG Speed — The current speed at which the LAG is operating.
• Admin Flow Control — Enables or disables flow control or enables the auto negotiation of flow
control on the LAG.
• Current Flow Control — The user-designated Flow Control setting.
Configuring LACP
Aggregate ports can be linked into link-aggregation port-groups. Each group is comprised of ports with
the same speed, set to full-duplex operations.
Aggregated Links can be manually setup or automatically established by enabling Link Aggregation
Control Protocol (LACP) on the relevant links. Aggregate ports can be linked into link-aggregation port-
groups. Each group is comprised of ports with the same speed. To define LACP:
1. Click Bridging > Port Managing > LACP. The LACP Page opens:
