Chapter 5: Configuring Device Interfaces
Configuring LACP
SGE2000/SGE2000P Gigabit Ethernet Switch Reference Guide
Chapter
5
LACP Page
The LACP Page contains fields for configuring LACP LAGs.
• LACP System Priority — Indicates the global LACP priority value. The possible range is 1-
65535. The default value is 1.
• Unit Number — Displays the stacking member for which LACP information is defined.
• Port — Defines the port number to which timeout and priority values are assigned.
• Port Priority — Defines the LACP priority value for the port. The field range is 1-65535.
• LACP Timeout — Administrative LACP timeout. The possible field values are:
– Short — Defines a short timeout value.
– Long — Defines a long timeout value. This is the default value.
Modify LACP Parameter Settings
1. Click Bridging > Port Managing > LACP. The LACP Page opens:
2. Click the Edit button. The LACP Parameter Settings Page opens:

Cisco SGE2000 Specifications

General

Jumbo Frame Support	9KB
VLANs	Up to 256
Management	Web-based, SNMP, CLI
Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1Q, 802.1p, 802.1w
Dimensions	440 x 44 x 257 mm
Power Supply	100 to 240V AC, 50-60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Weight	3.2 kg
