Chapter 13: Managing System Files
Active Image
SGE2000/SGE2000P Gigabit Ethernet Switch Reference Guide
Chapter
13
Active Image Page
The Active Image Page contains the following fields:
• Unit No. — Indicates the unit number for which the Image file is selected.
• Active Image — Indicates the Image file which is currently active on the unit.
• After Reset — The Image file which is active on the unit after the device is reset. The possible field
values are:
– Image 1 — Activates Image file 1 after the device is reset.
– Image 2 — Activates Image file 2 after the device is reset.
2. Define the relevant fields.
3. Click Apply. Active image is define, and the device is updated.

Cisco SGE2000 Specifications

General

Jumbo Frame Support	9KB
VLANs	Up to 256
Management	Web-based, SNMP, CLI
Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1Q, 802.1p, 802.1w
Dimensions	440 x 44 x 257 mm
Power Supply	100 to 240V AC, 50-60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Weight	3.2 kg
