Chapter 16: Viewing Statistics
Managing RMON Statistics
SGE2000/SGE2000P Gigabit Ethernet Switch Reference Guide
Chapter
16
Modify History Control Settings
1. Click Statistics > RMON > History. The RMON History Control Page opens.
2. Click the Edit button. The History Control Settings Page opens:
History Control Settings Page
The History Control Settings Page contains the following fields:
• History Entry Number — Displays the entry number for the History Control Table page.
• Source Interface — Displays the interface from which the history samples were taken. The possible
field values are:
– Port — Specifies the port from which the RMON information was taken.
– LAG — Specifies the port from which the RMON information was taken.
• Owner — Displays the RMON station or user that requested the RMON information. The field
range is 0-20 characters.
• Max No. of Samples to Keep — Indicates the number of samples to save.
• Sampling Interval — Indicates in seconds the time that samplings are taken from the ports. The
field range is 1-3600. The default is 1800 seconds (equal to 30 minutes).
3. Define the relevant fields.
4. Click Apply. The history control settings are defined, and the device is updated.

Cisco SGE2000 Specifications

General

Jumbo Frame Support	9KB
VLANs	Up to 256
Management	Web-based, SNMP, CLI
Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1Q, 802.1p, 802.1w
Dimensions	440 x 44 x 257 mm
Power Supply	100 to 240V AC, 50-60 Hz
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70°C (-4 to 158°F)
Humidity	10% to 90% non-condensing
Weight	3.2 kg
