Required Equipment
Before you begin the installation, ensure that you have the following items:
•
Number 1 and number 2 Phillips-head screwdrivers with torque measuring capabilities
•
Tape measure and level
•
ESD wrist strap or other grounding device
•
Antistatic mat or antistatic foam
Unpacking and Inspecting the Chassis
When handling chassis components, wear an ESD strap and handle modules by the carrier edges only.Caution
Keep the shipping container in case the chassis requires shipping in the future.Tip
The chassis is thoroughly inspected before shipment. If any damage occurred during transportation or any
items are missing, contact your customer service representative immediately.
Note
Procedure
Step 1
Remove the chassis from its cardboard container. Save all packaging material.
Step 2
Compare the shipment to the equipment list provided by your customer service representative and verify that
you have received the following items:
•
Any printed documentation
• Tool-less rack-mount kit (N20-CRMK2=)—mounting rails can be installed in a rack without the use of
tools. The optional round hole adapter kit (N20-CRMK2-RHA=) does require tools.
•
ESD wrist strap
•
Cables with connectors (including the N20-BKVM=, which is the KVM/local I/O console dongle)
•
Any optional items ordered
Step 3
Verify that all unused blade slots and power supply bays have blank covers.
Cisco UCS 5108 Server Chassis Installation Guide
45
Installation
Required Equipment
