Twinax Copper Cables for the UCS 6324 Fabric Interconnect
Twinax copper cables are available in various lengths for the UCS 6324 Fabric Interconnect. The 7 meter and
10 meter cables are active, which means that they contain active components with the SFP+ connector housing
to improve signal quality. The ends of these cables have connectors that can plug directly into SFP receptacles.
Table 13: Twinax Copper Cables
DescriptionModel
10-Gb Ethernet—copper SFP+ (1 m, 3.28 ft.)
SFP-H10GB-CU1M
10-Gb Ethernet—copper SFP+ (3 m, 9.84 ft.)
SFP-H10GB-CU3M
10-Gb Ethernet—copper SFP+ (5 m, 16.4 ft.)
SFP-H10GB-CU5M
10-Gb Ethernet—copper SFP+ (7 m, 22.9 ft.)
SFP-H10GB-ACU7M
10-Gb Ethernet—copper SFP+ (10 m, 32.8 ft.)
SFP-H10GB-ACU10M
QSFP+ Copper Optical Transceivers for the UCS 6324 Fabric Interconnect
Each UCS 6324 Fabric Interconnect supports up one copper/optical transceiver.
Table 14: QSFP+ Copper/Optical Transceivers
DescriptionModel
40GBASE-CR4 QSFP+ to four 10GBASE-CU SFP+ direct attach
breakout cable assembly, 5 meter passive
QSFP-4SFP10G-CU5M
40GBASE-CR4 QSFP+ to four 10GBASE-CU SFP+ direct attach
breakout cable assembly, 3 meter passive
QSFP-4SFP10G-CU3M
40GBASE-CR4 QSFP+ to four 10GBASE-CU SFP+ direct attach
breakout cable assembly, 1 meter passive
QSFP-4SFP10G-CU1M
40GBASE-CR4 QSFP+ to four 10GBASE-CU SFP+ direct attach
breakout cable assembly, 7 meter active
QSFP-4x10G-AC7M
40GBASE-CR4 QSFP+ to four 10GBASE-CU SFP+ direct attach
breakout cable assembly, 10 meter active
QSFP-4x10G-AC10M
Cisco UCS 5108 Server Chassis Installation Guide
65
Installation
Twinax Copper Cables for the UCS 6324 Fabric Interconnect
