APPENDIX A
Technical Specifications
This appendix lists the technical specifications for the Cisco UCS 5108 server chassis and includes the
following sections:
•
KVM Cable, page 85
•
Chassis Specifications, page 86
•
Environmental Specifications, page 87
•
Specifications for the Cisco UCS 5108 Blade Server Chassis Power Supply Units, page 88
•
Supported AC Power Cords and Plugs, page 91
KVM Cable
The KVM cable (N20-BKVM) provides a connection into a Cisco UCS blade server, providing a DB9 serial
connector, a VGA connector for a monitor, and dual USB ports for a keyboard and mouse. With this cable
you can create a direct connection to the operating system and the BIOS running on a blade server.
Figure 50: KVM Cable for Blade Servers
VGA connection for a monitor3Connector to blade server slot1
Cisco UCS 5108 Server Chassis Installation Guide
85
