Cisco UCS 5108 Installation Guide

2-port USB connector for a mouse and keyboard4DB9 serial connector2
Chassis Specifications
Table 15: Cisco UCS Server Chassis
SpecificationDescription
10.5 in (26.7 cm) x 17.5 in (44.5 cm) x 32 in (81.2 cm)Height x Width x Depth
8Blade server slots
2FEX slots
8Fan module bays
4Power supply bays
1.2 Tb aggregateBackplane throughput
Table 16: Weight of the Chassis Components
SpecificationDescription
90 lbs (40.83 kg)Empty chassis
2.5 lbs (1.13 kg)FEX
2.5 lbs (1.13 kg)UCS 6324 Fabric Interconnect
1.8 lbs (0.82 kg)Fan module
13.5 lbs (6.1 kg)
5
B200 Blade Server
18.0 lbs (8.16 kg)
5
B230 Blade Server
25 lbs (11.34 kg)
5
B250 Blade Server
34.5 lbs (15.65 kg)
5
B440 Blade Server
0.8 lbs (0.36 kg)Hard drive
Approximately 255 lbs (115.66 kg), depending on
models and options selected
Fully Populated UCS 5108 Server Chassis
Cisco UCS 5108 Server Chassis Installation Guide
86
Technical Specifications
Chassis Specifications

Cisco UCS 5108 Specifications

General

Number of Blade Slots	8
I/O Module Bays	2
Supported Blade Servers	Cisco UCS B-Series Blade Servers
Power Supply Options	Up to four hot-swappable power supplies (AC or DC)
Cooling	Redundant hot-swappable fans
Management	Cisco UCS Manager
Blade Slots	8
Fabric Interconnects	Cisco UCS 6100 or 6200 Series
Power Supplies	Up to 4 hot-pluggable power supplies
Form Factor	6RU rack-mountable
