201

INJECTION

CHECKING THE AIR SUPPLY CIRCUIT

Engine: 4HX

ESSENTIAL: Respect the safety and cleanliness recommendations.

Tool.

[1] Manual vacuum pump : FACOM DA 16

Checks.

ESSENTIAL: Respect the safety and cleanliness recommendations

that are specific to high pressure diesel injection (HDi) engines.

B1HP1ARP

Angl.T3-page191-206-2005 4/02/05 15:05 Page 201
