BRAKES

285

BRAKE SPECIFICATIONS

Tightening torques (m.daN).

(12) Brake fluid pressure sensor on master-cylinder : 2,5 ± 0,5

(16) Fixing of gyrometer/accelerometer sensor on support : 0,9 ± 0,1

(17) Fixing of support on body : 0,9 ± 0,1

Piping on master-cylinder : 1,5 ± 0,3

B3FP7A0C

B3FP79ZC
