CITROEN C8 2005 - Adjusting the Handbrake

To Next Page

To Previous Page

295

BRAKES

ADJUSTING THE HANDBRAKE

Identification

(A) Zone for fixing on floor

(B) Clips for retaining on bodyshell

B3FK263D

Angl.T3-page282-299-2005 4/02/05 15:29 Page 295
