CITROEN C8 2005 - Vehicle with Suspension Hydractive 3 +

To Next Page

To Previous Page

313

HYDRAULICS

B3BP16KC

B3BP16JC

DE-PRESSURISING THE HYDRAULIC SUSPENSION CIRCUIT

Vehicle with suspension Hydractive 3 +.

Front suspension: undo the pressure release screw (3) by one turn.

Wait for the pressure in the hydraulic circuit to drop fully.

Rear suspension: undo the pressure release screw (4) by one turn.

Wait for the pressure in the hydraulic circuit to drop fully.
