CITROEN C8 2005 - Page 355

To Previous Page

351

AIR

CONDITIONING

AIR CONDITIONING SYSTEM (R 134.a)

Engines: RHM - RHT - RHW - 4HW

1 - Drying cartridge

2 - Clickfit union (tool 8005-T.C)

3 - Buffer capacity

4 - Clickfit union (tool 8005-T.A)

5 - High pressure valve

6 - Low pressure valve

C5HP17UP

Angl.T3-page322-351-2005 4/02/05 15:38 Page 351
