WS2H and WS3 Manual Page 5
Software Version Power Supply
V3242-01BOARD Main Board
1
V3243-01BOARD
System Board
Output
Voltage
Part # and Description
114.10
1.03
24 VAC
V3461
2
WS2H/3 AC ADAPTER
V3461EU WS2H/3 AC ADAPTER EU
V3461UK WS2H/3 AC ADAPTER UK
114.11
115.17
1.07 or 1.08115.25
200.01
215.02
1.11 or 1.13215.03
215.04
215.10 1.11 or 1.13 20 VAC
3
V3461-01 WS2H/3 AC ADAPTER 20V
V3461EU-01 WS2H/3 AC ADAPTER EU 20V
V3461UK-01 WS2H/3 AC ADAPTER UK 20V
216.04 or greater 1.13 or greater
20 VAC
18 VAC
V3461-01 WS2H/3 AC ADAPTER 18V
V3461EU-01 WS2H/3 AC ADAPTER EU 18V
V3461UK-01 WS2H/3 AC ADAPTER UK 18V
SOFTWARE AND POWER SUPPLY COMPATIBILITY
TABLE 2
1
It is recommended to maintain one version throughout a system.
2
Replacement V3461 power supplies have screw terminals and are shipped less a cord. Use cord from existing power
supply to connect to the screw terminals.
3
V3461EU-01 and V3461UK-01 will not be available for sale until August 2010.
COMMUNICATION CABLE CONNECTION TO PC BOARD LAYOUT
A
C
View Of Revised 3 Wire Communication
Cable On 4 Terminal Header
View Of 4 Wire Communication Cable On 3
Terminal Header (System Board Is Optional)
3 Wire Cables Being Installed On 4
Terminal Headers Need Left Polarizer
"Ear" Removed
Install right side of cable flush
to terminal leaving a vacant
position on the left of the cable
Install cable flush to the
right side leaving left terminal
pin with no connection
Remove
Ear
Revised communication cable connectivity.
Refer to diagram (below) when combining 3- and 4-wire communication hardware.
