Page 28 WS2H and WS3 Manual
INSTALLER 1
INSTALLER 2
INSTALLER 3
INSTALLER 4
INSTALLER 5
RETURN TO NORMAL
OPERATION
INSTALLER SETUP SCREENS
Accessed by pressing NEXT and UP simultaneously for >3 seconds.
Set current day and regen days when set
as a 7 day time clock in System Setup 1.
See next page.
INSTALLER 1 – Set Volumetric Capacity
Capacity: Set the units Volumetric Capacity in
gallons or cubic meters
OFF
• Units will not regenerate based on volume
but will track usage history
• Will not be an option on units with no day
override set
INSTALLER 2 – Set Days Between Regenerations (Day override)
Set day override. 1-28 days between regenerations, or if set to 7 day time clock, see 7 day
setup on next page. OFF will only be displayed if “OFF” is selected in System Setup 4.
• Settings will be based on the type of day override control set in system setup.
• Off will be displayed for units with day override turned off
1 – 28: When set as a 28 day override
• Set the days between regens
1 – 7: When set as a 7 day timeclock
• First, set 1 – 7 to signify the current day (1 = Sunday – 7 = Saturday)
• Next turn regen on or off for each speci c day of the week, 1 - 7
INSTALLER 3 – Set Delayed Regeneration Time
• Set the delayed time of regeneration, hour (AM / PM toggles at midnight)
• Units with no time dependent control (Aux Input settings or Day Override) will display on0
INSTALLER 4 – Set Delayed Regeneration Time
• Set delayed time of regeneration, minutes
INSTALLER 5 – Set Multiple Delayed Regeneration Times
• When con gured for multiple delayed regeneration times, repeat steps 3 & 4 for each
additional time slot
X1000 Indicator Illuminates At 10,000
Gallons
Units
Range Increments
US
(GAL)
10-10,000
10,000-100.00 x 1000
100.00-999.00 x 1000
10
100
1000
SI
(L)
50-50,000
50,000-50.00 x 1000
500.00-5000.0 x 1000
50
50
5000
To Next Page
