Controls
The 2-Wire Intercom Type Select Switch determines the type of 2-Wire intercom that may be
connected to the corresponding 2-Wire connectors on the rear panel of the BaseStaon. Clear-Com,
RTS, or BAL (AudioCom) can be selected. These switches only aect 2-Wire operaon and do not
control 4-Wire operaon. The CHAN A&B switch selects the 2-Wire system type for both the A and
the B intercom channels.
The Intercom Channel Select (SEL) buon selects one of the two intercom channels to allow
selecon of 2-Wire or 4-Wire funconality and to allow the intercom audio IN and OUT levels to
be adjusted.
Pressing the Intercom Channel Select buon once selects Menu Mode on the BaseStaon and
displays the Intercom Levels screen on the LCD display. A second press selects channel A. The
intercom channel selected is indicated by one of the two CHAN LEDs located to the right of the
CHAN SEL buon and on the LCD screen. Addional presses of the CHAN SEL buon advances
through the remaining intercom channels. The next press of the CHAN SEL buon will exit Menu
Mode and will cause all of the LEDs to be illuminated.
The 2-Wire/4-Wire Select (SEL) buon selects the connecon mode for operaon of each
of the two intercom channels. Pressing the 2-Wire/4-Wire Select (SEL) buon changes the
selected intercom mode between 2-Wire, 4-Wire or no wired connecon. In Operaonal
Mode, the four 2-Wire/4-Wire LEDs indicate the currently selected hardwired intercom
connecon mode for each of the intercom channels: 2-Wire, 4-Wire, or no wired intercom
connecon.
The IN and OUT controls adjust the intercom volume level coming in to the Tempest BaseStaon from
the hardwired intercom system or out to the hardwired intercom from the BaseStaon. In addion,
these knobs adjust Aux IN/OUT levels.
To adjust the levels press the CHAN SEL buon to enter Menu mode, CHAN SEL again to advance
to the desired channel and rotate the IN or OUT controls. Note that the LCD display indicates the
currently selected levels.
Intercom Channel volume levels are expressed in Decibels (dB):
» IN: -10.5 through +5.5
» OUT: -10.5 through +5.5
Always set the 2-Wire Intercom Type Select Switches prior to connecng the 2-Wire
intercom to the back of the Tempest BaseStaon. Never change the switch seng while
connected to a wired intercom system. Failure to follow this procedure could damage the
Tempest BaseStaon or the 2-Wire hardwired system.
The IN and OUT controls are only acve in Menu Mode.
