ComAp IGS-NT Series - Possible Connections Per Port

IGS-NT Installation Guide
104
12.2. Possible Connections per Port
Port Type
On
Hardware
Number of
Connections
Available Connections
RS232(1)
Any
1
InteliVision 8
PC
Modbus terminal
Modem
RS485(1)
IG-NT-BB
IG-NTC-BB
IM-NT-BB
IM-NTC-BB
2
InteliVision 8
InteliVision 5
IG-Display
RS485(1)
IS-NT-BB
IS-NTC-BB
3
InteliVision 8
InteliVision 5
IS-Display
RS485(1)
IG-NT
IG-NTC
IM-NT
1
InteliVision 8
PC
Modbus terminal
Modem
RS232(2)
Where
available
1
InteliVision 8
PC
Modbus terminal
Modem
RS485(2)
Where
available
1
InteliVision 8
PC
Modbus terminal
Modem
CAN1
Any
45
AIN (10x)
BIN (12x)
AOUT (4x)
BOUT (12x)
DENOX20 (1x)
ECON3 (1x)
ECON4 (1x)
Other specialized HW
CAN2
Any
35
Controllers
InteliVision 8
IG-IB
I-LB+
InternetBridge-NT
USB
Where
available
1
PC
Ethernet
Where
available
2
Standard Ethernet Connection
NOTE:
RS232(1) – RS485(1) and RS232(2) – RS485(2) can be switched and only one port at a time
is available for communication.
