20.17.5. RS232 interface
Maximal distance 0m
Speed p to 19.2kbps (depends on ECU type
connected)
20.18. I-LB
Voltage supply -36V DC
Consumption ,1A depend on supply voltage
Operating temperature -30..+70
o
C
Mechanical dimensions: 5 x 96 x 43 mm , DIN rail (35 mm)
mounted
Interface to modem or PC S232, RS422, RS485, (USB – I-LB+
version)
Interface to controller AN
20.19. IG-IB
Voltage supply -36V DC
Consumption ,1A depend on supply voltage
Mechanical dimensions: 5 x 96 x 43 mm , DIN rail (35 mm)
mounted
Interface to controller S232 or CAN
Interface to modem S232
Interface to Ethernet J45 (10baseT)
Operating temperature -30..+70
o
C
Storage temperature -30..+70
o
C
20.20. I-RBxx
Number of relays: 6 or 8 in sockets
Nominal voltage: 4 VDC
Voltage range: 6,8 – 36 VDC
Relay opens at: 0% of nominal voltage
Electric / mechanic cycles: 00 000 / 10 000 000
Operating temperature range: 40°C to 70°C
Maximal load: 6 A resistive load at 24VDC
4 A inductive load at 24 VDC
(I-RBxx-231) 2 A at 231VAC
Contacts protection: aristor 14DK390
20.21. IG-MTU
Primary voltage Ph-Ph x400 VAC / 50Hz (3x480 VAC / 60 Hz)
Secondary voltage Ph-N x 230 V AC ( 3x277 VAC / 60 Hz) , 5 VA
Mechanical dimensions: 5 x 95 x 60 mm , DIN rail (35 mm)
mounted
