ComAp IGS-NT Series - Is-Ntc-Bb; Schematics

IGS-NT Installation Guide
59
NOTE:
* IG-MTU or IG-MTU-2-1 can be used for three wire systems, systems with separated
Neutral or when galvanic separation between generator or mains voltage and controller is
required.
** When more devices connected to RS485 bias resistor jumpers should be closed only on
one of them.
7.6. IS-NTC-BB
7.6.1. Schematics
(1)
EXTENSION
MODULES
INTERCONTROLLER
& MONITORING
DISPLAY
L
H
L
H
InteliSys
NTC
BaseBox
Order code: IS-NTC-BB
LB 9
( PROG. CNTRL.)
4XC2
Made in EU, Czech Republic
LB 9
LB 9
MAX 0,74 A
LB 9
LB 9

Left to right: Pull down Bias / 120Ω / Pull up Bias / 120Ω / 120Ω

Down: AI4 setting / AI3 setting / AI2 setting / AI1
setting
Current input 0-25mA
Voltage input 0-5V
SG OUT setting
PWM VoutR VOut





