ComAp IGS-NT Series - Intelivision 8 Wiring

IGS-NT Installation Guide
43
6.1.8. InteliVision 8 Wiring
6.1.8.1. General Guidelines
RS232
RS485 CAN
L HA B
120 Ω
120 Ω
To RS485(1)
or (2)
To CAN2
6.1.8.2. Connection to IG-NT
RS232
RS485
CAN1
Extension
CAN2
Intercontroller
Terminal 1*:
InteliVision 8
Communication:
InteliVision 8
Channel 1
InteliVision 8
Channel 2
InteliVision 8
Channel 3
InteliVision 8
Channel 4
InteliVision 8
HINT
*Only one external display can be connected to the control unit via RS485(1) – IG-DISP port.
