bus is enabled by DeadBusClosing
 binary input BTB disable is not closed
 it is enabled by setting of Synchro enable, Mains
coupling setpoints
12.2.2.18 Setpoint: Local buttons
Group
Basic settings
Range [units]
PANEL, EXTBUTTONS, BOTH [-]
Related FW
3.0
Description
The setpoint selects which set of control buttons is currently active. Its function
depends on which type of controller is used. Please refer to the section which
suits your controller/display version.
 First section deals with the case of IGS-NT with built-in monochrome
display.
 Second section deals with the case of IGS-NT-BB with IV5 display.
 Third section deals with the case of IGS-NT-BB with IV8.
NOTE:
If you have IGS-NT (built-in display) and you use additional IV display all the
sections may be relevant (depending on the type of additional displays).
IGS-NT (built-in monochrome display)
PANEL
The built-in buttons on the controller front panel (IG-NT) or
terminal #1 (IS-NT) are enabled, the binary inputs for
external buttons are disabled.
EXTBUTTONS
The built-in buttons are disabled and the binary inputs for
external buttons are enabled.
BOTH
Both built-in buttons and binary inputs for external buttons
are enabled.
NOTE:
In case that additional IV display is connected to a controller it behaves in the
way described below.
NOTE:
