7.5.2. Terminals, Inputs and Outputs
Function
Terminals
Note
Generator voltage
L1,L2,L3, (N)
3x120 / 277 Ph-N or 207 / 480 Ph-Ph VAC
(neutral not needed), max 350 / 600VAC *,
CAT III
Mains/Bus voltage
L1,L2,L3, (N)
3x120 / 277 Ph-N or 207 / 480 Ph-Ph VAC
(neutral not needed), max 350 / 600VAC,
CAT III
Generator current
L1k,L1l, L2k,L2l,
L3k,L3l
0 ÷ 5 Amps, max 10 A all time, 150 A for 2
sec
0 ÷ 1 Amp, max 2 Amps all time
Neutral/Mains
current
LNk,LNl
0 ÷ 5 Amps, max 10 A all time, 150 A for 2
sec
0 ÷ 1 Amp, max 2 Amps all time
IG-AVRi interface
AVRI-OUT, AVRI-
COM
TTL (5V PWM) interface to IG-AVRi
Power supply
+ , -
8 ÷ 36 VDC
D+
D plus
Inputs and outputs
Binary inputs
BI1 ÷ BI6
BI7 ÷ BI12
Activation to minus power supply.
Binary outputs
BO1 ÷ BO6
BO7 ÷ BO12
Load is connected to plus or to minus power
supply. (defined in GenConfig).
Analog inputs
AI1 ÷ AI4
Ohms, mA, Volts sensors
Analog outputs
SG-OUT, SG-COM
Speed governor output interface (10V / 5V
PWM; 500 – 3000Hz)
RPM
RPM-IN, RPM-COM
Min 2 Vpk-pk (from 4 Hz to 4 kHz)
Communication interface
RS232 (1)
D SUB9 (male)
PC: InteliMonitor, GenConfig or
Modem, GSM modem or
ECU (e.g. Cummins ModBus) or InteliVision
8
RS485 (Display) **
A, B, COM
Up to 3 IS-Displays (Remote display), up to 3
InteliVision 8 displays (remote display) or 3
InteliVision 5.
RS485 (2) **
A ,B ,COM
Redirected RS232 (2) – see Basic settings:
RS485(2)conv.
PC: InteliMonitor, GenConfig
or Modem, GSM modem or InteliVision 8
USB
Electrical isolated
2.0 slave
PC: InteliMonitor, GenConfig
CAN1
L, H, COM
Extension modules: IS-AIN, IS-BIN,IGS-
PTM, IGL-RA15, I-AOUT
CAN2
L, H, COM
Intercontroller (Load&VAR sharing, Power
management), monitoring (IG-IB, I-LB) and
up to 4 InteliVision 8
RJ45 (Ethernet)
Ethernet cable
Remote monitoring via Ethernet,
InteliMonitor, WebSupervisor and etc…
