ComAp IGS-NT Series - Analog Inputs; Analog Output; Is-Ain8

IGS-NT Installation Guide
144
20.12.3. Analog inputs
Not electrically separated
Number of inputs 4
Resolution 10 bits
Maximal resistance range 0 – 250 
Maximal voltage range 0 – 100 mV
Maximal current range 0 – 20 mA
Resistance measurement tolerance 1 %  2  out of measured value
Voltage measurement tolerance 1,5 %  1mV out of measured value
Current measurement tolerance 2,5 % 0,5mA out of measured value
20.12.4. Analog output
Not electrically separated
Number of inputs 1
Resolution 10 bits
Output range 0 to 20 mA ± 0,33 mA
20.13. IS-AIN8
Nominal power supply 24 VDC
Power supply range 8 – 36 VDC
Max. consumption 250 mA
Mechanical dimensions: 150 x 160 x 50 mm ,
DIN rail (35 mm) mounted
Connection to controller (galvanically separated) CAN1
Operating temperature -40..+70
o
C
Storage temperature -40..+80
o
C
Protection front panel IP 20
Humidity 95% without condensation
Standard conformity
Low Voltage Directive EN 61010-1:95 +A1:97
Electromagnetic Compatibility EN 50081-1:94 (EN 61000-6-3)
EN 50081-2:96 (EN 61000-6-4)
EN 50082-1:99 (EN 61000-6-1)
EN 50082-2:97 (EN 61000-6-2)
20.13.1. Analog inputs
Nominal power supply 24 VDC
Power supply range 8 – 36 VDC
Number of inputs 8
Not galvanic separated
Resolution 16 bits
