7.7. IM-NT
7.7.1. Schematics
Refer to installation instructions for torque values
IG-DISPLAY
B1
EXTENSION
CAN2
INTERCONTROLLER
A1
L1
H1
L2
COMR1
COMC1 COMC2
CAN1
CAUTION -
Risk of Electric Shock, Do Not Remove Cover.
No User Serviceable Parts Inside.
Refer servicing To Qualified Service Personnel.
InteliMains
NT
Order code: IM-NT GC
For Use on a Flat Surface of a Type 1 Enclosure.
Max. ambient temperature 70º C
Use Copper Conductors Only
DONGLE
H2
+ PWR BOUT
LB 6
www.comap.cz
Made in EU, Czech Republic
MAX 0.74A
for details
8 - 36 V
See instructions
LB 6
POWER
MAINS (BUS-L) CURRENT
0 – 1/0 - 5 A
BINARY
OUTPUTS
B01 B02 B03 B04 B05 B06
L1k
L1I L2k L2I L3k B3I IAk IAI
AUX
CURRENT
N/A N/A
N/A
BI1 BI2 BI3 BI4 BI5 BI6
MAINS(BUS-L)
VOLTAGE
MAINS (BUS-R)
VOLTAGE
N
N
L1
L1
L2
L2
L3
L3
BINARY
INPUTS
LB 6
3x277 /480 V
or
120 /207
3x277 /480 V
or
120 /207
RS 232(1)

Left to right: Pull down Bias / 120Ω / Pull up Bias / 120Ω / 120Ω

Boot jumper


